LED straatpaal reclame
LED straatpaal reclame
- Model: Street pole screen
- Street pole led display
- 3 jaar garantie
- CE, RoHS, FCC UL Goedgekeurd
- Product Description: P3 P4 P5 P6 P8 P10 Full Color Lighting Pole LED Display for Street
Street Pole LED Display Features:
1. The first level LED chip from Epistar and Kinglight
2. With pure golden wire connection in LED
3. Grand A raw material for module frame and mask
4. 4 layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when the assembly
6. Disassembly and assembly are quick and easy
7. 3 years warranty
8. Energy-saving 60 %: driving with low-frequency current, heat-dissipated roller fans with the automatic temperature-controlling device.
9. Lifetime >11 years;
Product Details
Installation and Accessories
Street Light Pole Specifications:
Pixel pitch | 4 mm | 5mm | ||
Pixel specification | 1R1G1B | |||
Physical density | 62500dot/m2 | 40000dot/m2 | ||
Plate Size | 512mmx1024mm、768mmx1536mm、1024mmx1792mm | 640mm×1280mm、800mm×1600mm、960mm×1920mm | ||
Kijkhoek | x>140° y>140° | |||
Helderheid | ≥5500cd/m2 | ≥4000cd/m2 | ||
Refresh Rate | ≥600Hz | |||
Grijze schaal | 256 Levels with RGB individual adjustment | |||
Driving method | 1/8 sweep constant current drive | |||
Werking Vermogen | 220V±10％ | |||
Ave.Power Consumption | 500W/m2 | 400W/m2 | ||
Max.Power Consumption | 1200W/m2 | 1000W/m2 | ||
Video Signa | RF、S-Video、RGB、RGBHV、YUV、YC、COMPOSITION | |||
Besturingsmodus | PCTV card (optional) + DVI graphics card + Master card + optical fiber transmission | |||
Levensduur | 50000 hours | |||
Storage Temp | -40℃ ～ +80℃ | |||
Operating Temperature | -20℃ ～ +50℃ | |||
Relatieve vochtigheid | 10%～95% | |||
Protection Level | IP65 | |||
